Mechanical Brake Actuator – V Mount

Description

V-mount mechanical brake actuator, designed for use with trailers equipped with a cable-operated (mechanical) braking system. Manufactured from steel with a zinc-plated finish, it ensures high corrosion resistance and durability during constant use.

Features

V-mount (angled chassis mounting)
Total length: 621.8 mm
Body length (side view): 306.3 mm
Width between mounting arms: 205.0 mm
Distance between mounting holes: 160.0 mm
Total height: 120.0 mm
Mounting angle: 36.2°
Mounting hole diameter: Ø 13.0 mm
Zinc-plated, corrosion-resistant finish
Available in 3 towing capacities: 1,000 kg, 1,500 kg, and 2,500 kg

SPECIFICATIONS

Code	Description	Capacity
205508	Mech. Brake Actuator C700/1000KG V-Mount	1,000 kg
205509	Mech. Brake Actuator C950/1500KG V-Mount	1,500 kg
205510	Mech. Brake Actuator C1450/2500KG V-Mount	2,500 kg
