PEDESTAL LIGHT 01 SMOOTH

Description

Designed for light-duty trailers, providing stable support while parked and easy maneuverability. The clamp mounting system enables quick installation and removal, making it ideal for applications requiring frequent repositioning of the trailer jack.

Features

Part Number: 207005R
Description: Light 01 Smooth Trailer Jack
Maximum Static Load Capacity: 150 kg
Maximum Dynamic Load Capacity: 150 kg
Wheel Diameter: 6" (Ø 150 mm)
Wheel Width: 46 mm
Mounting Type: Clamp Mount
Tube Diameter: Ø 44.45 mm
Compatible U-Bolt Mount: Ø 44.45 mm
Adjustment Range: Retracted: 430 mm (±5 mm) | Extended: 650 mm (±5 mm)
Operation: Top Side Crank Handle
